Combi Chiller(Top) & Freezer (Bottom) SCTC-210

Combi Chiller(Top) & Freezer (Bottom) SCTC-210

Dim : 2100*590*1168

Request a Quote
Voltage/frequency 220~240V/50HZ
Refrigerant R290
Foaming agent Top: Cyclopentane,60MM thickness
Bottom: Cyclopentane,70MM thickness
Climate 25℃,60% Rh
Inner temperature -22~-18℃
Volume (L) 559+900
Product Dimension  WxDxH (mm) Top: 2100*590*1022
Bottom: 2104*850*1080
after connecting2100*890*2110
Packing Dimension  WxDxH(mm) Top: 2190*660*1155
Bottom: 2234*994*1205
Net weight(kg) only top unit 188
Gross weight(kg) only top unit 203
Container Loads 40GP/ 40HQ 14 Sets
Door type Top: 3 Hinged,self-closing
Bottom: 3 Sliding
Glass door Top: Three glazed, external toughen glass with heater lowe
Cabinet White, painted steel
Inside walls White, painted aluminum
Door frame Aluminum
Door handle Extruded, Full length
Branding Optional
Cooling system Top: Fan cooling
Bottom: Static cooling
Defrosting Automatic
Evaporator Top: Copper fin block
Bottom: Al roll bond
Evaporator fan motor 3
Condenser Steel wire
Condenser fan motor 3
Light Top: 2 horizontal canopy+ 2 cabinet, LED
Bottom: 2 cabinet, LED
Light switch Yes
Temperature controller Digital
Water tray Self-evaporation
Shelf (Material / No.) Top: Reinforced wire shelf,6 pcs
Bottom: 4 pcs
K clips and shelf support liners Stainless steel
Price tag Top: Optional
Bottom: YES
Light box Yes
Lock & key No
